Everest ESW-116P 16 Port 10 / 100Mbps Switch Hub
Product Code 32399
Barcode: 8680096082924
| Explanation | Switch HUB |
| Brand | Everest |
| Model | ESW-116P |
| Color | Brown |
| Standard | IEEE802.3/u/x/ab |
| Interface | RJ45 |
| Port | RJ45 Female |
| Number of Ports | 16 Pieces |
| Power Supply | AC 100V - 240V, 0.4A, 50/60Hz |
| Data transfer | 10 BASE-T UTP CAT3/4/5 Cable, 100 BASW-TX UTP CAT5/5e Cable |
| Data transfer rate 10/100 | 10Mbps: 14880pps, 100Mbps: 148800pps |
| Led Indicator | 16 Pieces Link/Act, 1 Piece Power |
| Capacity | 3.2 Gbps (Switching Capacity) |
| Data Transmission Method | Store and Forward |
| MAC Adress Table | 4k |
| Speed | 10/100Mbps |
| Storage Temperature | (-40) ~ (+70) C degree |
| Storage Humidity | 5% ~ 90% non-condensing |
| Operating Temperature Range | 0 ~ (+45) C degree |
| Operating Humidity Ratio | 10% ~ 90% non-condensing |
| Product Weight | 1.53Kgr ±5gr |
| Product size | 44mm x 183mm x 440mm |
| Gross Weight | 2.21Kgr ±5gr |
| Package Dimension | 82mm x 286mm x 530mm |
| Box contents | Product + AC Power Cable + Mountage Apparatus + Warranty/Hand Manual |
| Warranty Time | 24 Months |
